The Series EWDP Wireless Communication Adjustable Differential Pressure Switch uses EnOcean® wireless technology to monitor pressure, vacuum, and differential pressures. The dual scaled adjustment knob in inches of water column and pascals allows changes to the pressure set point to be made without a pressure gage. The battery-powered switch is equipped with radio module for frequencies of 902 MHz or 868 MHz which sends a signal wirelessly to a Series USB-300 receiver (sold separately) at each change of status. The silicone diaphragm makes this series ideal for use with air and other non-combustible gases. The EWDP is available with settings from 0.08 in w.c. (20 Pa) up to 20 in w.c. (5000 Pa). The compact size, adjustment knob, and wireless capabilities make the EWDP the perfect choice for HVAC applications in temporary installations or retrofits of existing buildings.
Made in USA. brand DWYER, model EWDP
International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.
Retail price from $213
Available
Founded in 1931, DWYER manufactures equipment for measurement, conversion and control – pressure, temperature, level, flow.
Only the best I&C brands
Our company is a UAE supplier of control and measuring instruments from well-known world brands
Discounts for organisations
We sell high-tech equipment at best prices. We provide really advantageous conditions for partners
Fast delivery across the Middle East
Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries
Professional advice on device selection
Our specialists are ready to advise you on any technical question. We can find an analogue of any device
PRODUCT APPLICATIONS
| Photo | Model | Description |
|---|---|---|
|
A-288 | Brackets & Magnets for Easy Installation |
| A-480 | Static Pressure Sensors – 4" Insertion Depth – For Manometers & Gages |
| Model | Description | Availability | Price | Qty | Buy |
|---|---|---|---|---|---|
| EWDP-03-2-L-E | EnOcean®-Enabled Differential Pressure Switch, .2-2.01" w.c., M20x1.5 connection, low voltage gold plated, 868 MHz | Delivery time from 12 weeks | from 219$ |
-
+
|
|
| EWDP-03-2-L-N | EnOcean®-Enabled Differential Pressure Switch, .2-2.01" w.c., M20x1.5 connection, low voltage gold plated, 902 MHz | Delivery time from 12 weeks | from 213$ |
-
+
|
|
| EWDP-04-2-L-N | EnOcean®-Enabled Differential Pressure Switch, .12-1.61" w.c., M20x1.5 connection, low voltage gold plated, 902 MHz | Delivery time from 12 weeks | from 226$ |
-
+
|
|
| EWDP-04-2-L-N-C | EnOcean®-Enabled Differential Pressure Switch, .12-1.61" w.c., M20x1.5 connection with installer kit, low voltage gold plated, 902 MHz | Delivery time from 12 weeks | from 232$ |
-
+
|
|
| EWDP-05-2-L-N-C | EnOcean®-Enabled Differential Pressure Switch, .8-4.01" w.c., M20x1.5 connection with installer kit, low voltage gold plated, 902 MHz | Delivery time from 12 weeks | from 219$ |
-
+
|
|
| EWDP-07-2-L-N | EnOcean®-Enabled Differential Pressure Switch, 4-20" w.c., M20x1.5 connection, low voltage gold plated, 902 MHz | Delivery time from 12 weeks | from 226$ |
-
+
|
|
| EWDP-07-2-L-N-C | EnOcean®-Enabled Differential Pressure Switch, 4-20" w.c., M20x1.5 connection with installer kit, low voltage gold plated, 902 MHz | Delivery time from 12 weeks | from 219$ |
-
+
|
|
| EWDP-08-2-L-N | EnOcean®-Enabled Differential Pressure Switch, .08-1.2" w.c., M20x1.5 connection, low voltage gold plated, 902 MHz | Delivery time from 12 weeks | from 226$ |
-
+
|
|
| A-480 | Plastic static pressure tip | Delivery time from 12 weeks | from 2$ |
-
+
|
|
| A-481 | Installer kit, (includes 2 static pressure tips and PVC tubing). | Delivery time from 12 weeks | from 7$ |
-
+
|
|
| A-489 | 4" 303 SS straight static pressure tip with flange, 1/4" hose barb. | Delivery time from 12 weeks | from 10$ |
-
+
|
|
| A-289 | “S° type metal mounting bracket with screws. | Delivery time from 12 weeks | from 6$ |
-
+
|
|
| A-288 | “L° type metal mounting bracket with screws. | Delivery time from 12 weeks | from 6$ |
-
+
|
You can request the necessary certificates, documentation, instructions and user guide for DWYER EWDP using the special form.
You can buy DWYER EWDP in UAE at a price starting from 213 $ in «Texair FZCO» by leaving a request on the website, by phone +441225535040 or by email rop@texairmeasure.ae. DWYER EWDP price are subject to change depending on exchange rates. We deliver instruments by transport companies in United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain and other Middle Eastern countries.
