The TracXP TXP-FDE IR3-HD triple IR flame detector ensures the highest immunity to false alarms and provides an ultra-fast response, high performance, and reliable detection of all types of hydrocarbon fires (visible and non-visible).
The IR3-HD’s high definition camera allows clear imaging of fire and personnel at 100ft (30m). Video recording of one-minute pre-event and up to three minutes post-event provides visual documentation of the event.
Made in USA. brand MACURCO, model TXP-FDE IR3-HD
International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.
price По запросу
Available
Only the best I&C brands
Our company is a UAE supplier of control and measuring instruments from well-known world brands
Discounts for organisations
We sell high-tech equipment at best prices. We provide really advantageous conditions for partners
Fast delivery across the Middle East
Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries
Professional advice on device selection
Our specialists are ready to advise you on any technical question. We can find an analogue of any device
The detector addresses slow-growing fires as well as the fast eruption of fire using improved triple IR (IR3) technology. Integral event recording provides the ultimate safety tool to protect your personnel, plant, and processes.
Applications
Key features
| Dimensions | 7.87″ (L) x 5.12″ (W) x 5.12″ (H) |
| Shipping Weight | 15.2 lbs. (6.9 kg.) |
| Power & Electrical | Operating Voltage: 18-32 VDC Current (Standby): 180 mA Current (Maximum): 300 mA Conduit Entries: 2 x 3/4″ NPT or M25x1.5 Wiring: 12-20 AWG |
| Outputs | Relays: 3 x SPST 2A @ 30 VDC Analog: 4-20 mA stepped (sink or source) Digital: Modbus RS-485 RTU LED: Tri-color (Green, Yellow and Red) |
| HART | HART® 7 for configuration & maintenance |
| Detection Time and Distance | 40ms for fast burst or explosion For 1 sq. ft. (0.1 sq. m.) n-heptane pan fire: 1.5s at 0-100 ft. (0-30 m) 9s at 100-262 ft. (30-80 m) |
| Sensitivity Options | Extreme, High, Medium, Low and Very Low |
| Field of View | 90° Horizontal and 75° Vertical |
| Time Delay | 0-30 seconds |
| Built-in-Test (BIT) | Automatic (Upon startup and in 20 minute intervals) Manual (PC software or wire terminal short) |
| Temperature Range | -67°F to +185°F (-55°C to +85°C) |
| Humidity | Up to 99% (RH), non-condensing |
| Ingress Protection | IP66 & 68; NEMA 4X & 6P |
| Approvals | Refer to Table on Page 3 |
Video Specifications
| HD Video | Color HD as standard |
| Alarm Recording | 1-minute pre- and up to 3 minutes post-event |
| Integration Protocol | ONVIF (Open Network Video Interface Forum) |
| Digital Video | IP network IEEE 802.3 100Base-T |
| Composite Video | NTSC or PAL |
| 84-1112-1200-10 | TXP-FDE IR3-HD, Video, SS, 3/4″ NPT, Tilt Mount |
| 84-1112-1100-20 | TXP-FDE IR3-HD, Video, SS, M25, Tilt Mount |
| 84-2112-1200-10 | TXP-FDE IR3-H2-HD, Video, SS, 3/4″ NPT, Tilt Mount |
| 84-2112-1100-20 | TXP-FDE IR3-H2-HD, Video, SS, M25, Tilt Mount |
| 84-1211-1200-10 | TXP-FDE IR3, No Video, SS, 3/4″ NPT, Tilt Mount |
| 84-1211-1100-20 | TXP-FDE IR3, No Video, SS, M25, Tilt Mount |
| 84-2211-1100-20 | TXP-FDE IR3-H2, No Video, SS, 3/4″ NPT, Tilt Mount |
| 84-2211-1200-10 | TXP-FDE IR3-H2, No Video, SS, M25, Tilt Mount |
| Photo | Model | Description |
|---|---|---|
|
84-1000-0000-08 | TXP-FDE IR3, SS, Flame Simulator Kit |
|
|
84-2000-0000-08 | TXP-FDE IR3-H2, SS, Flame Simulator Kit |
| 84-8000-0000-04 | TXP-FDE Weather Cover for Models without Video | |
|
84-8000-0000-08 | TXP-FDE Pole Mount Adapter, SS, 2” & 3” |
| 84-8000-0000-05 | TXP-FDE USB to RS-485 PC Converter Kit | |
|
84-8000-0000-01 | TXP-FDE HD Weather Cover |
| 84-8000-0000-10 | TXP-FDE HD Duct Mount Kit without Sapphire Window | |
| 84-8000-0000-11 | TXP-FDE HD Duct Mount Kit with Sapphire Window | |
| 84-8000-0000-12 | TXP-FDE HD Airshield for Dust and Snow Protection | |
| 84-8000-0000-13 | TXP-FDE HD Paint and Dust Shield Adapter Ring Kit | |
| 84-8000-0000-14 | TXP-FDE HD Disposable Paint and Dust Shields (Qty. 10) |
