Moisture Generator with Powerful Features to Run Automated Calibrations
Made in United Kingdom. brand Michell, model ADG400
International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.
price По запросу
Available
Only the best I&C brands
Our company is a UAE supplier of control and measuring instruments from well-known world brands
Discounts for organisations
We sell high-tech equipment at best prices. We provide really advantageous conditions for partners
Fast delivery across the Middle East
Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries
Professional advice on device selection
Our specialists are ready to advise you on any technical question. We can find an analogue of any device
The ADG400 is designed for use as part of a hygrometry calibration system. It is capable of repeatable generation of dew points across a range of -80 °C…+20 °C, when used in conjunction with the Michell Instruments PSD2 pressure swing dryer.
The generation technique is based on the volumetric mixing of dry and wet gases. It gives the fastest response when changing between set points in comparison to other dew-point generator technologies (such as two-temperature, two-pressure or a combination of both).
The HMI allows the dew point to be changed and automated calibration profiles to be designed and run. The USB interface allows remote control of the HMI and integration with customer software.
Applications
| Technical Specifications | |
| Performance | |
| Output Range | -80 °C…+20 °C dew point |
| Output Stability | < 0.05 °C |
| Repeatability | 0.5 °C |
| HMI | Full-color touch screen |
| Set Points | 11-point factory setup set-point table @ 10 °C intervals. 13-point user configurable set-point table |
| Operating Modes | Manual, Timed Profile, Remote Command |
| Electrical Specifications | |
| Digital Communications | USB (Virtual Serial Port) for remote operation of HMI via a PC, or changing set points via remote commands |
| Power Supply | IEC Socket
80…264 V AC (47…63 Hz) or 113…370 V DC |
| Power Consumption | 400 VA Max. |
| Operating Specifications | |
| Operating Temperature | 23 °C ±3 °C (73.4 °F ±5.4 °F) |
| Storage Temperature | 5 °C…50 °C (41 °F…122 °F) |
| Gas Input Requirements | Compressed air from PSD2 Pressure Swing Dryer, set up with ADG400 as matched pair |
| Gas Input Pressure | 2.0 barg (29.0 psig) |
| Gas Input Flow Rate | 7 Nl/min |
| Gas Input Moisture Content | < 0.4 ppmV |
| Gas Output Flow Rate | 5 Nl/min from -80 °C…-10 °C frost point, 4 Nl/min at 1 °C decreasing to 1 Nl/min at +20 °C dew point |
| Mechanical Specifications | |
| Enclosure | Painted aluminum |
| Dimensions | 19” Subrack, 12U Height, ~360 mm Depth |
| Filtration | Inlet particulate filter |
| Gas Connections | 6 mm Swagelok® Tube |
| Weight | 23 kg |
You can request the necessary certificates, documentation, instructions and user guide for Michell ADG400 using the special form.
You can buy Michell ADG400 in UAE at a price starting from По запросу $ in «Texair FZCO» by leaving a request on the website, by phone +441225535040 or by email rop@texairmeasure.ae. Michell ADG400 price are subject to change depending on exchange rates. We deliver instruments by transport companies in United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain and other Middle Eastern countries.
