Made in USA. brand MSA Safety, model ALTAIR 4XR
International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.
price По запросу
Available
Only the best I&C brands
Our company is a UAE supplier of control and measuring instruments from well-known world brands
Discounts for organisations
We sell high-tech equipment at best prices. We provide really advantageous conditions for partners
Fast delivery across the Middle East
Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries
Professional advice on device selection
Our specialists are ready to advise you on any technical question. We can find an analogue of any device
| Specification | Description | ||
| GAS TYPES | Gas | Range | Resolution |
| LEL | 0-100% | 1% | |
| O2 | 0-30% | 0.1% | |
| CO | 0-1999 ppm | 1 ppm | |
| H2S | 0-200 ppm | 1 ppm | |
| H2S-LC | 0-100 ppm | 0.1 ppm | |
| SO2 | 0-20 ppm | 0.1 ppm | |
| NO2 | 0-50 ppm | 0.1 ppm | |
| WARRANTY | 4 years (+ optional 1-year extension) | ||
| DURABILITY | 25 ft. (7.5 m) drop protection MIL-STD-810G drop protection Certified IP68 rating | ||
| TEMPERATURE RANGE | -40°F to +140°F -40°C to +60°C | ||
| RELATIVE HUMIDITY | 5% – 95% intermittent 15% – 90% non-condensing | ||
| POWER | Rechargeable Li-polymer battery with nominal runtime of 20 hours at 25 °C, and 7 hours at -20°C. <4 hour charge time | ||
| PHYSICAL | 4.4″ x 3.0″ x 1.4″ 11 cm x 7.6 cm x 3.5 cm 8 oz (228 g) | ||
| DATALOGGING | > 50 hours (adjustable) > 500 event logs | ||
| Weight | 7.9 oz./224 g (device with battery and clip) |
| Dimensions (L x W x H) | 4.4 x 3.00 x 1.37 inches/112 x 76 x 33 mm – without fastening clip |
| Alarms | Four gas alarm LEDs, a charge status LED, an audible alarm and a vibrating alarm |
| Volume of audible alarm |
95 dBA at 30 cm typical |
| Display | LCD display |
| Battery type | Rechargeable Li polymer battery. Must not be charged in Ex area. |
| Device run time (Bluetooth OFF) |
20 hours at 25 °C (77 °F) Device run time is reduced nominally by 10% with Bluetooth enabled and nominally by 15% with the Backlight configured to always on. If both Bluetooth and the backlight are on the nominal runtime reduction will be 25%. |
| Charging time | 4 hours
The maximum safe area charging voltage Um = 6.7 VDC |
| Warm up time | 2 min |
| Atmospheric pressure range | 800 to 1200 mbar |
| Ingress protection | IP 68 (2 meters for 45 minutes) |
| Measuring methods | Combustible gases: Catalytic sensor Oxygen: Electrochemical sensor Toxic gases: Electrochemical sensor |
You can request the necessary certificates, documentation, instructions and user guide for MSA Safety ALTAIR 4XR using the special form.
You can buy MSA Safety ALTAIR 4XR in UAE at a price starting from По запросу $ in «Texair FZCO» by leaving a request on the website, by phone +441225535040 or by email rop@texairmeasure.ae. MSA Safety ALTAIR 4XR price are subject to change depending on exchange rates. We deliver instruments by transport companies in United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain and other Middle Eastern countries.
