UMR14 Sensors contain a rugged transducer potted in a stainless steel housing. Outputs respond to measured distance and non-contact technology means nothing touches your materials
Made in USA. brand OMEGA, model UMR14
International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.
Retail price from $682.13
Available
Only the best I&C brands
Our company is a UAE supplier of control and measuring instruments from well-known world brands
Discounts for organisations
We sell high-tech equipment at best prices. We provide really advantageous conditions for partners
Fast delivery across the Middle East
Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries
Professional advice on device selection
Our specialists are ready to advise you on any technical question. We can find an analogue of any device
316SS,14ft Range,1″ NPT,Multiple Outputs,RS-232
UMR14 Sensors and OmegaVIEW software put the power of ultrasonics in your hands yet retain the simplicity of push-button TEACH setup. You can quickly adjust, optimize, save and clone your applications without calibration. The UMR14 Sensors are designed to address close up and medium working distance requirements up to 14 ft. Narrow beam width and shortened minimum range gives closeup versatility. Serial data and analog outputs respond to measured distance. Non-contact technology means nothing touches your materials.
| Product Number | Category | Media Type | Max Measurement Range | Accuracy | Tank/Vessel Type | Max Operating Pressure | Max Process Temperature | Wetted Materials | Output Signal | Process Connection Type | Process Connection Size | Supply Power | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
UMR14-1NPT-232 $981.45
|
Ultrosonic
|
Any
|
10.2 cm to 4.3 m (4″ to 14′)
|
+/- 0.5%
|
Any
|
50 psi
|
70°C (158°F)
|
316 SS
|
Two Outputs
|
MNPT
|
1″
|
10 to 30 Vdc
|
Configurable with OmegaVIEW software, or with TEACH pushbutton. IP 68 Ingress rating. RS-232
|
|
UMR14-1NPT-485 $682.13
|
Ultrosonic
|
Any
|
10.2 cm to 4.3 m (4″ to 14′)
|
+/- 0.5%
|
Any
|
50 psi
|
70°C (158°F)
|
316 SS
|
Two Outputs
|
MNPT
|
1″
|
10 to 30 Vdc
|
Configurable with OmegaVIEW software, or with TEACH pushbutton. IP 68 Ingress rating. RS-485
|
|
UMR14-30MM-232 $682.13
|
Ultrosonic
|
Any
|
10.2 cm to 4.3 m (4″ to 14′)
|
+/- 0.5%
|
Any
|
50 psi
|
70°C (158°F)
|
316 SS
|
Two Outputs
|
Metric
|
M30
|
10 to 30 Vdc
|
Configurable with OmegaVIEW software, or with TEACH pushbutton. IP 68 Ingress rating. RS-232
|
|
UMR14-30MM-485 $682.13
|
Ultrosonic
|
Any
|
10.2 cm to 4.3 m (4″ to 14′)
|
+/- 0.5%
|
Any
|
50 psi
|
70°C (158°F)
|
316 SS
|
Two Outputs
|
Metric
|
M30
|
10 to 30 Vdc
|
Configurable with OmegaVIEW software, or with TEACH pushbutton. IP 68 Ingress rating. RS-485
|
You can request the necessary certificates, documentation, instructions and user guide for OMEGA UMR14 using the special form.
You can buy OMEGA UMR14 in UAE at a price starting from 682.13 $ in «Texair FZCO» by leaving a request on the website, by phone +441225535040 or by email ceo@texair.eu. OMEGA UMR14 price are subject to change depending on exchange rates. We deliver instruments by transport companies in United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain and other Middle Eastern countries.
