PLAST-O-MATIC RVT/RVTX Angle Pattern 2-way

Name: PLAST-O-MATIC RVT/RVTX Angle Pattern 2-way
Brand: PLAST-O-MATIC

Series RVT/RVTX is a high capacity angle pattern valve for relief, bypass, backpressure and pump backpressure applications with excellent corrosion resistance. 1/2″ – 2″ sizes in most popular thermoplastic materials and connections; 5 – 125 PSI set range. 3″ size provides settings 5 – 100 PSI.

			int(20613)
NULL

Made in USA. brand PLAST-O-MATIC, model RVT/RVTX

International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.

price По запросу

Available

Only the best I&C brands

Our company is a UAE supplier of control and measuring instruments from well-known world brands

Discounts for organisations

We sell high-tech equipment at best prices. We provide really advantageous conditions for partners

Fast delivery across the Middle East

Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries

Professional advice on device selection

Our specialists are ready to advise you on any technical question. We can find an analogue of any device

Descriptions of PLAST-O-MATIC RVT/RVTX

FEATURES:

PTFE shaft prevents chatter and sticking.
Triple U-cup seal isolates spring, provides added safety.
Patented Fail-Dry advance warning vent allows maintenance to be scheduled conveniently, without costly shut-down.
Angle pattern offers compact size and convenient piping.
1/2″ through 2″ pipe sizes.
No wetted metal parts.

Technical specifications of PLAST-O-MATIC RVT/RVTX

DESIGN:

Series RVT angle pattern pressure relief valve features a solid, nonsticking PTFE shaft passing through three U-cup seals.
It is a proven, high performance relief valve providing rugged dependability for acids and other highly corrosive liquids.
Relief setting is infinitely adjustable from 5 psi to 125 psi.
Maximum inlet pressure is 150 psi.
Not recommended for salt solutions and other liquids that can crystallize.

MATERIALS OF CONSTRUCTION:

Available in PVC, CPVC, Natural Polypropylene, PVDF and PTFE.
Seals are available in EPDM or FKM (Viton).
For alternate body, seal materials, or coated fasteners, consult factory. The adjusting
bolt, lock, nut and fasteners are stainless steel.
The control spring is plated steel. No metal parts are in contact with liquid.

User Guide and Instruction manual for PLAST-O-MATIC RVT/RVTX

You can request the necessary certificates, documentation, instructions and user guide for PLAST-O-MATIC RVT/RVTX using the special form.
