The digital output module serves to display information, issue alarms and control events.
Made in Swiss. brand Rotronic, model RMS-DO-L-R
International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.
Retail price from $453
Available
Only the best I&C brands
Our company is a UAE supplier of control and measuring instruments from well-known world brands
Discounts for organisations
We sell high-tech equipment at best prices. We provide really advantageous conditions for partners
Fast delivery across the Middle East
Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries
Professional advice on device selection
Our specialists are ready to advise you on any technical question. We can find an analogue of any device
The digital output module serves to display information, issue alarms and control events. The relays can be interrogated or set via Modbus TCP or the RMS software. It is possible to define the conditions in the RMS software and to actuate the outputs on the basis of them.
Compatible with:
Applications
| General specifications | |
| Device type | RMS-DO-L-R |
| Number of outputs | 2, polarity-independent |
| Range of application | -40..70 °C / 0..100 %RH non-condensing |
| Storage conditions | -40..30 °C / 0..95 %RH |
| Maximum altitude | 2000 m ASL |
| Power supply | 24 VDC ±10 % / <100 mA / PoE: 802.3
af-2003, Class 1 |
| AC adapter requirements | 24 VDC ±10 % / 4 W nominal /<15 W power-limited |
| Device data | |
| Interface | Digital signal / galvanically isolated |
| Relay switching capacity | 50 VAC (peak) 1 A / 50 VDC/1 A, polarity- independent |
| Voltage output (VEX) | 24 VDC (Note: The maximum current avail- able depends on the external power supply connected.) |
| Max. cable length at input | <3 m |
| Measurement interval | >=10 s |
| Interface | Ethernet |
| Protocols | HTTP |
| Conformity with standards | |
| FDA / GAMP directives | FDA CFR21 Part 11 / GAMP 5 |
| Housing / Mechanical parts | |
| Housing material | Polycarbonate (PC) |
| Fire protection class | UL94-V0 |
| Dimensions | 89.7 x 62.2 x 108 mm |
| IP protection class | IP20 |
| Weight | 155 g |
You can request the necessary certificates, documentation, instructions and user guide for Rotronic RMS-DO-L-R using the special form.
You can buy Rotronic RMS-DO-L-R in UAE at a price starting from 453 $ in «Texair FZCO» by leaving a request on the website, by phone +441225535040 or by email rop@texairmeasure.ae. Rotronic RMS-DO-L-R price are subject to change depending on exchange rates. We deliver instruments by transport companies in United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain and other Middle Eastern countries.
See also: Rotronic Monitoring System RMS
