The AG1800 Aerosol Generator produces aerosol particles in a wide range of diameters.
Support OEM/ODM service.
Made in China. brand ZETRON, model AG-1800
International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.
price По запросу
Available
Only the best I&C brands
Our company is a UAE supplier of control and measuring instruments from well-known world brands
Discounts for organisations
We sell high-tech equipment at best prices. We provide really advantageous conditions for partners
Fast delivery across the Middle East
Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries
Professional advice on device selection
Our specialists are ready to advise you on any technical question. We can find an analogue of any device
AG-1800 type aerosol generator is a portable generator. It is designed according to the principle of generation, heating generation type of aerosol generator.
AG-1800 type can be applied to a broader flow rate of 1500 ~ 65000 cfm, can meet the use of high efficiency filter testing of large flow rates.
Aerosol generator is a device to generate smoke, DOP solvent (or PAO solvent) poured into the generator container, under certain pressure heating conditions can produce aerosol smoke, the aerosol smoke will be sent to the upwind side of the high-efficiency filter (DOP liquid heating, the formation of DOP vapor, the vapor condensed into tiny droplets under specific conditions, remove the too large and too small droplets, leaving only 0.3 μm (about particles, mist DOP into the air duct).
The aerosol generator can be equipped with an optional nozzle connector to direct the aerosol particles generated by the aerosol generator upstream of the high efficiency filter.
Application
| Usable flow rate range | 1,500-65,000 cfm (42-1,839.5 m3/min) |
| Occurrence concentration | Flow rate 65,000 cfm (at approx. 1839.5 m3/min) |
| Particle generation | PAO, DOP, polydispersed |
| Generation method | Heating generation |
| Compressed gas (inert) | Nitrogen, Argon, Carbon Dioxide or Helium (50 psi)) |
| Power supply | AC 220～240 VAC, 50/60 HZ |
| Dimension | 280×390×300 mm |
| Weight | Approx. 14kg |
You can request the necessary certificates, documentation, instructions and user guide for ZETRON AG-1800 using the special form.
You can buy ZETRON AG-1800 in UAE at a price starting from По запросу $ in «Texair FZCO» by leaving a request on the website, by phone +441225535040 or by email rop@texairmeasure.ae. ZETRON AG-1800 price are subject to change depending on exchange rates. We deliver instruments by transport companies in United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain and other Middle Eastern countries.
See also: Aerosol generators for clean room
