UM3000 series is innovative water meter including IoT communication function. Without installing IoT device separately, meter data can be transmitted.
Features:
Made in South Korea. brand ISTEC, model UM3000
International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.
price По запросу
Available
Only the best I&C brands
Our company is a UAE supplier of control and measuring instruments from well-known world brands
Discounts for organisations
We sell high-tech equipment at best prices. We provide really advantageous conditions for partners
Fast delivery across the Middle East
Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries
Professional advice on device selection
Our specialists are ready to advise you on any technical question. We can find an analogue of any device
| UM3000 series | |||
| Model | UM30158/UM3015N | UM30208/UM3020N | UM30258/UM3025N |
| Nominal diameter | 15 mm | 20 mm | 25 mm |
| Length of spool | 165 mm | 190 mm | 225 mm |
| Flow range Q1 | 0.0064 m³/h | 0.01 m³/h | 0.016 m³/h |
| Flow range Q3 | 1.6 m³/h | 2.5 m³/h | 4.0 m³/h |
| Flow range Q4 | 2.0 m³/h | 3.125 m³/h | 5.0 m³/h |
| Communication | NB-IoT / LoRa | ||
| Flow ratio (G3/Q1) | 250/400 | ||
| Accuracy | Q1–Q2 : ±5% Q2–Q4±2% | ||
| Life span | Over 10 years | ||
| Spool material | Lead-free brass & pps | ||
| Reading method | TTL(UART) | ||
| MCU | Low-power 16bit MCU | ||
| Temperature | -20°C – 60°C | ||
| Water proof | IP68 | ||
| Reading interval | 1 hour (chargeable from 1 to 24hours) | ||
| Communication interval | 4 times/day (chargeable from 1 to 4times) | ||
You can request the necessary certificates, documentation, instructions and user guide for ISTEC UM3000 using the special form.
You can buy ISTEC UM3000 in UAE at a price starting from По запросу $ in «Texair FZCO» by leaving a request on the website, by phone +441225535040 or by email rop@texairmeasure.ae. ISTEC UM3000 price are subject to change depending on exchange rates. We deliver instruments by transport companies in United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain and other Middle Eastern countries.
