Flame simulators are often used by industry to perform detector testing during commissioning and periodic system testing. The TXP-FDE simulators are inexpensive, lightweight and simple to use. The modern ergonomic design, with alignment markers, allows accurate, fast and convenient detector performance verification. Suitable for use in hazardous areas, the TXP-FDE flame simulators can be used at distances of up to 23 feet (7 meters) from the detector.
Made in USA. brand MACURCO, model TXP-FDE Simulator Kit
International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.
price По запросу
Available
Only the best I&C brands
Our company is a UAE supplier of control and measuring instruments from well-known world brands
Discounts for organisations
We sell high-tech equipment at best prices. We provide really advantageous conditions for partners
Fast delivery across the Middle East
Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries
Professional advice on device selection
Our specialists are ready to advise you on any technical question. We can find an analogue of any device
The TXP-FDE Flame Simulator provides fast and convenient detector verification in the field.
Three different models are available for testing each type of TXP-FDE Flame Detector (IR3, IR3-H2 and UV-IR).
All TXP-FDE flame detectors perform automatic self-tests of their optics, windows, electronics and software. Additionally, the TXP-FDE flame detectors can be manually put into alarm via the PC communicator software or by short circuiting the “Manual BIT” terminal and the “24 VDC (-)“ terminal for one second. The TXP-FDE flame test simulators are designed to complement these inbuilt features by providing a fully external loop test capability.
Applications
Key features
| Simulator Kit Part Numbers | TXP-FDE IR3 Kit | TXP-FDE IR3-H2 Kit | TXP-FDE UV/IR Kit | |
| Detector Type | TXP-FDE IR3 | TXP-FDE IR3-H2 | TXP-FDE UV/IR | |
| TXP-FDE IR3-HD | TXP-FDE IR3-H2-HD | TXP-FDE UV/IR-HD | ||
| Operation Distances | Detector Sensitivity | ft. m | ft. m | ft. m |
| Extreme | 23.0 7.0 | 23.0 7.0 | 21.3 6.5 | |
| High | 16.0 5.0 | 16.0 5.0 | 16.0 5.0 | |
| Medium | 10.0 3.0 | 10.0 3.0 | 13.0 4.0 | |
| Low | 3.3 1.0 | 3.3 1.0 | 3.3 1.0 | |
| Electrical Specifications | Operating Voltage nominal, V | 3.7 | 3.7 | 3.7 |
| Number of Activations between charging | ~1000 | ~1000 | ~50 | |
| Battery Capacity, mAh | >3000 | >3000 | >3000 | |
| Charging time, hours | up to 3 | up to 3 | up to 3 | |
| Indication | 3 color LED (Green, Yellow, Red) | |||
| All Simulator Models | ||||
| Mechanical Specifications | Size | 3.9 x 3.9 x 7.8″ (100 x 100 x 200mm) | ||
| Weight | 3.96 lbs. (1.8 kg) | |||
| Simulator Enclosure Material | Painted Aluminum LM25 | |||
| Environmental Specifications | Ingress Protection | IP65 (NEMA 4X) | ||
| Humidity | up to 99% (RH), non-condensing | |||
| Operating temperature | Min: -4°F (-20°C) Max: +122°F (+50°C) | |||
| Approvals | Explosion proof | ATEX Ex II 2 G Ex db ib op is IIC T6 Gb Ex II 2 D Ex tb ib op is IIIC T85°C Db -20°C<Ta<+50°C | ||
| Included in Kits | Carrying case, carrying strap, cover tool, allen key, battery charger and spare battery | |||
| Warranty | 3 Years | |||
You can request the necessary certificates, documentation, instructions and user guide for MACURCO TXP-FDE Simulator Kit using the special form.
You can buy MACURCO TXP-FDE Simulator Kit in UAE at a price starting from По запросу $ in «Texair FZCO» by leaving a request on the website, by phone +441225535040 or by email rop@texairmeasure.ae. MACURCO TXP-FDE Simulator Kit price are subject to change depending on exchange rates. We deliver instruments by transport companies in United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain and other Middle Eastern countries.
