The TXP-FDE UV/IR detects fires and explosions extremely quickly allowing mitigation steps to be initiated more rapidly and limit event escalation.
Made in USA. brand MACURCO, model TXP-FDE UV/IR
International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.
price По запросу
Available
Only the best I&C brands
Our company is a UAE supplier of control and measuring instruments from well-known world brands
Discounts for organisations
We sell high-tech equipment at best prices. We provide really advantageous conditions for partners
Fast delivery across the Middle East
Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries
Professional advice on device selection
Our specialists are ready to advise you on any technical question. We can find an analogue of any device
The TXP-FDE UV/IR flame detector provides ultra-fast response, high performance and reliable detection of a large variety of fires including hydrocarbon fires (visible and non-visible), H 2 and CH 4 /H 2 mixed fires. The detector addresses slow growing fires and fast eruptions of fire using improved UV & IR technology operating in all weather and light conditions. The HD model provides high-definition color video of the monitored area with clear imaging of fire events and personnel at distances up to 100 ft. Video and event data are stored to non-volatile memory. Recordings start one minute before detection and continue for up to four minutes to assist with post incident investigation
Applications
Key features
| Dimensions | 5.51″ (L) x 3.54″ (W) x 3.54″ (H) |
| Shipping Weight | 9.9 lbs. (4.5 kg.) |
| Power & Electrical | Operating Voltage: 18-32 VDC Current (Standby): 120 mA Current (Maximum): 180 mA Conduit Entries: 2 x 3/4″ NPT or M25x1.5 Wiring: 12-20 AWG |
| Outputs | Relays: 3 x SPST 2A @ 30 VDC Analog: 4-20 mA stepped (sink or source) Digital: Modbus RS-485 RTU LED: Tri-color (Green, Yellow and Red) |
| HART | HART® 7 for configuration & maintenance |
| Detection Time and Distance | 5ms for fast burst of explosion For 1 sq. ft. (0.1 sq. m.) n-heptane pan fire: 1s at 0-50 ft. (0-15 m) <2s at 50-100 ft. (15-30 m) |
| Sensitivity Options | Extreme, High, Medium and Low |
| Field of View | 90° Horizontal and 80° Vertical |
| Time Delay | 0-30 seconds |
| Built-in-Test (BIT) | Automatic (Upon startup and in 20 minute intervals) Manual (PC software or wire terminal short) |
| Temperature Range | -67°F to +185°F (-55°C to +85°C) |
| Humidity | Up to 99% (RH), non-condensing |
| Ingress Protection | IP66 & 68 (2m, 24hr); NEMA 4X & 6P |
| Approvals | Refer to Table on Page 3 |
| 84-3211-1100-20 | TXP-FDE UV/IR, No Video, SS, 3/4″ NPT, Tilt Mount |
| 84-3211-1200-10 | TXP-FDE UV/IR, No Video, SS, M25, Tilt Mount |
| 84-4211-1200-10 | TXP-FDE UV/IR-F, No Video, SS, 3/4″ NPT, Tilt Mount |
| 84-4211-1100-20 | TXP-FDE UV/IR-F, No Video, SS, M25, Tilt Mount |
| 84-3112-1200-10 | TXP-FDE UV/IR-HD, Video, SS, 3/4″ NPT, Tilt Mount |
| 84-3112-1100-20 | TXP-FDE UV/IR-HD, Video, SS, M25, Tilt Mount |
| 84-4112-1200-10 | TXP-FDE UV/IR-F-HD, Video, SS, 3/4″ NPT, Tilt Mount |
| 84-4112-1100-20 | TXP-FDE UV/IR-F-HD, Video, SS, M25, Tilt Mount |
*Coordinates shown are for TXP-FDE UV/IR models only.
| Photo | Model | Description |
|---|---|---|
|
84-3000-0000-08 | TXP-FDE UV/IR, SS, Flame Simulator Kit |
| 84-8000-0000-04 | TXP-FDE Weather Cover for Models without Video | |
| 84-8000-0000-05 | TXP-FDE USB to RS-485 PC Converter Kit | |
|
84-8000-0000-08 | TXP-FDE Pole Mount Adapter, SS, 2” & 3” |
|
84-8000-0000-01 | TXP-FDE HD Weather Cover |
| 84-8000-0000-10 | TXP-FDE HD Duct Mount Kit without Sapphire Window | |
| 84-8000-0000-11 | TXP-FDE HD Duct Mount Kit with Sapphire Window | |
| 84-8000-0000-12 | TXP-FDE HD Airshield for Dust and Snow Protection | |
| 84-8000-0000-13 | TXP-FDE HD Paint and Dust Shield Adapter Ring Kit | |
| 84-8000-0000-14 | TXP-FDE HD Disposable Paint and Dust Shields (Qty. 10) |
You can request the necessary certificates, documentation, instructions and user guide for MACURCO TXP-FDE UV/IR using the special form.
