PLAST-O-MATIC PRS Stabilizer for Air Loaded Pressure Regulators

Name: PLAST-O-MATIC PRS Stabilizer for Air Loaded Pressure Regulators
Brand: PLAST-O-MATIC

Series PRS patented Stabilizer is used with Series PRA. The Stabilizer reacts to downstream liquid pressure and provides continuous feedback control to the compressed air supply, for even greater regulator sensitivity and performance. This is a Specialty Custom product; consult factory for availability. Minimum quantities may apply.

			int(20554)
NULL

Made in USA. brand PLAST-O-MATIC, model PRS

International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.

Data Sheet PLAST-O-MATIC PRS

price По запросу

Available

Only the best I&C brands

Our company is a UAE supplier of control and measuring instruments from well-known world brands

Discounts for organisations

We sell high-tech equipment at best prices. We provide really advantageous conditions for partners

Fast delivery across the Middle East

Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries

Professional advice on device selection

Our specialists are ready to advise you on any technical question. We can find an analogue of any device

Descriptions of PLAST-O-MATIC PRS

Used with an Air-Loaded Regulator, Series PRS reacts instantly to fluctuations in pressure, significantly enhancing the accuracy of the air-loaded regulator – downstream pressure has virtually no deviation from set pressure.
Desired pressure is maintained without sacrificing flow.
Performance rivals control valves, at much lower cost.
Ideal for applications with changing pressure requirements.
Can be conveniently teed into piping at desired control point, or may be mounted at a more convenient location and connected with tubing for process pressure sensing.
Easy to set; adjustable from 5 PSI to 100 PSI. Maximum pressure at control point is 150 PSI.
Teflon diaphragm for critical ultra-pure and corrosive liquid applications.
No wetted metal or elastomer parts.

Technical specifications of PLAST-O-MATIC PRS

Control Pressure Range	5 – 100 PSIG (.3 – 6.9 BAR)
Minimum Air Pressure	Set Pressure + 15 PSI (1.0 BAR)
Maximum Control Point Pressure	150 PSIG (10.3 BAR)
Air Pressure Ports	1/8″ NPT, female
Process Fluid Port	1/2″ NPT, male
Minimum Process Liquid Supply Pressure	Set Pressure + All Downstream Pressure Drops to Control Point + 15 PSI

Expand Table

Materials of Construction & Piping Connections:

Standard process connection is 1/2″ male NPT threaded, for alternate types, consult factory. Standard Air connections are 1/8″ female NPT.
Connection to regulator valve air chamber should be 1/4″ or larger tubing. Air chamber material is PVC. Process connections are available in Grade 1 Type 1 PVC, Natural Polypropylene, Kynar PVDF and Teflon.
Standard seal material is a Teflon diaphragm backed with Viton.
Adjusting bolt and external fasteners are stainless steel. A Buna-N rubber seal is used in the air chamber.
For materials other than listed, please consult factory.

User Guide and Instruction manual for PLAST-O-MATIC PRS

Data Sheet PLAST-O-MATIC PRS

You can request the necessary certificates, documentation, instructions and user guide for PLAST-O-MATIC PRS using the special form.
