YIDU E Gas mass flow meter

Description of YIDU E

The E series laminar mass gas flow meter is an improved version of the M series, featuring a more compact size and increased performance. Unique laminar differential technology combined with compensation implemented using high-precision pressure and temperature sensors, as well as proprietary key algorithms, provide the product with characteristics such as high accuracy, high repeatability, low zero drift, and low temperature and pressure drifts. Analog and digital communication interfaces are suitable for integration into process control systems.

Features

• Ultra-Precision: ±0.5% reading accuracy for high-end manufacturing gas control;
• Wide range: 0.5SCCM~5000SLPM, covering all range ranges required by the industry;
• Universal Compatibility: Supports industry-standard communication protocols and fluid connec- tions;
• Scalable Configurations: Optional high-temperature (-40°C~200°C), high-pressure (100 barg), low-pressure-drop, and fast-response (≤15ms) variants.

Principle Introduction

Laminar Mass Flow Meter Utilizing patented internally-compensated laminar differential pressure technology, this instrument integrates pressure and temperature sensors to fully compensate for discrepancies between volumetric and mass flow rates induced by thermal/pressure variations. It delivers rapid, precise real-time measurements of five critical parame- ters: : real-time temperature, pressure, volumetric flow, mass flow, and totalized flow， Should you require accurate and rapid gas flow measurement, leak rate detection, or a reference meter for measurement transfer and calibration applications, YIDU flow meters provide an optimal solution.

Application

• Flowability testing of precision components;
• leak rate quantification;
• Gas metering in pipeline systems;
• Calibration of gas flow.

Technical specifications of YIDU E
