Hot-swappable module for TestPro & NSA. Enables Tier-2 fiber certification and precise fault location without powering down the tester.
Made in USA. brand AEM, model AD-OTDR-U-1310_1550
International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.
Retail price from $2 600
Available
Only the best I&C brands
Our company is a UAE supplier of control and measuring instruments from well-known world brands
Discounts for organisations
We sell high-tech equipment at best prices. We provide really advantageous conditions for partners
Fast delivery across the Middle East
Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries
Professional advice on device selection
Our specialists are ready to advise you on any technical question. We can find an analogue of any device
The AEM AD-OTDR-U-1310_1550 is a singlemode OTDR test adapter for TestPro and Network Service Assistant (NSA) platforms. It operates at 1310 nm and 1550 nm and uses an SC/UPC interface. The adapter is hot-swappable, allowing connection without powering down the test equipment. It is used to locate broken fibers and loss events and, when combined with TestPro Tier-1 optical loss certification, supports Tier-2 certification.
Key Features
| Parameter | Specification |
|---|---|
| Product Name | Singlemode OTDR Test Adapter |
| Part Number | AD‑OTDR‑U‑1310_1550 |
| Compatibility | TestPro CV100, Network Service Assistant (NSA) |
| Wavelengths | 1310 nm ±25 nm; 1550 nm ±30 nm |
| Fiber Type | Singlemode |
| Connector Interface | SC/UPC |
| Event Dead Zone | 1310 nm: 0.6 m typical; 1550 nm: 0.6 m typical |
| Attenuation Dead Zone | 1310 nm: 3.6 m typical; 1550 nm: 3.7 m typical |
| Dynamic Range | 1310 nm: 29 dB; 1550 nm: 27 dB |
| Max Distance Range Setting | 130 km |
| Distance Measurement Range | 1310 nm: 80 km; 1550 nm: 130 km |
| Reflectance Range | –14 to –65 dB (both wavelengths) |
| Pulse Width | 3 … 25 000 nsec (programmable) |
| Hot‑swappable | Yes |
| Tier‑2 Certification | Supported (when combined with Tier‑1 optical loss test, TestPro only) |
| Kit Contents |
Note: OTDR launch cords are not included (ordered separately) |
You can request the necessary certificates, documentation, instructions and user guide for AEM AD-OTDR-U-1310_1550 using the special form.
You can buy AEM AD-OTDR-U-1310_1550 in UAE at a price starting from 2600 $ in «Texair FZCO» by leaving a request on the website, by phone +441225535040 or by email rop@texairmeasure.ae. AEM AD-OTDR-U-1310_1550 price are subject to change depending on exchange rates. We deliver instruments by transport companies in United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain and other Middle Eastern countries.
