DWYER ULSS ultrasonic level sensor

The Model ULSS Ultrasonic Level Sensor provides non-contact, continuous ultrasonic level measurement of fluids for short range applications. Ultrasonic technology paired with automatic temperature compensation provides accurate and reliable measurements in almost all conditions. The Model ULSS has failsafe logic that is easily configured to custom applications via free software removing the need for target calibration. Using the free software, the Model ULSS can be programmed to transmit an output signal as well as set the four relays for control applications. This rugged design comes with a NEMA 6P submersible enclosure rating to ensure a long lasting unit.

			int(1983)
NULL


Made in USA. brand DWYER, model ULSS

International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.

Retail price from $781.2

Available

Available

Founded in 1931, DWYER manufactures equipment for measurement, conversion and control – pressure, temperature, level, flow.

Advantages

Only the best I&C brands

Our company is a UAE supplier of control and measuring instruments from well-known world brands

Advantages

Discounts for organisations

We sell high-tech equipment at best prices. We provide really advantageous conditions for partners

Advantages

Fast delivery across the Middle East

Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries

Advantages

Professional advice on device selection

Our specialists are ready to advise you on any technical question. We can find an analogue of any device

Description of DWYER ULSS

PRODUCT APPLICATIONS

  • Water and wastewater
  • Pulp and paper processing
  • Sump and process tanks
  • Chemical processing
  • Food and beverage

FEATURES

  • Has a 4.1´ (1.2 m) measuring range with a 0.125″ (3 mm) accuracy
  • Via free software, units can be programmed to transmit an output signal and operate four relays for control applications
  • Provides reliable, accurate, and non-contact level measurement of compatible liquids
  • Non-contact technology offers no moving parts to wear, jam, corrode, or get coated like contact technologies
  • Mapping software makes effective measuring surface only a 3″ (76.2 mm) diameter column with no concerns of ladders, pipes, or other tank intrusions in the remaining sound cone
  • Ultrasonic technology paired with automatic temperature compensation provides accurate and reliable measurements in almost all conditions
  • Fail-safe logic is easily configured to custom applications via free software removing the need for target calibration
  • Full NEMA 6P submersible enclosure rating to ensure excellent product durability

Technical specifications of DWYER ULSS

  • Service: Compatible fluids.
  • Wetted Materials: Sensor: PVDF; O-ring: FKM.
  • Ranges: 4.1′ (1.25 m).
  • Accuracy: 0.125″ (3 mm).
  • Resolution: 0.019″ (0.5 mm).
  • Blind Zone: 2″ (5 cm).
  • Beam Width: 2″ (5 cm).
  • Temperature Limits: Process: 20 to 140°F (-7 to 60°C); Ambient: -31 to 140°F (-35 to 60°C).
  • Temperature Compensation: Automatic.
  • Pressure Limit: 30 psi (2 bar).
  • Power Requirement: 12 to 28 VDC.
  • Output Signal: 4 to 20 mA, 2-wire; Invert: 4 to 20 mA or 20 to 4 mA; Fail-safe: 4 mA, 20 mA, 21 mA, 22 mA, or hold last.
  • Loop Resistance: 400 Ω max.
  • Electrical Connections: 4′ (1.2 m) 9 conductor shielded cable.
  • Contact Type: 4 SPST relays.
  • Contact Rating: 1 A max @ 28 VDC max.
  • Deadband: Selectable (no hysteresis, 1/4″, 1/2″, 1″, 1/2 cm, 1 cm, 2 cm, 5 cm or not available).
  • Process Connection: 1″ NPT, 1″ BSPP (optional).
  • Enclosure Rating: NEMA 6P (IP68).
  • Enclosure Material: Polycarbonate; Gland: TPE.
  • Mounting Orientation: Vertical.
  • Memory: Non-volatile.
  • Failsafe: Contact: Power loss: Holds Last contact; Power on: Open, close, or last contact.
  • Programming: Free PC software download (USB adapter required).
  • Weight: 1 lb (0.45 kg).
  • Compliance: mCE.

Prices for

Model Description Availability Price Qty Buy
ULSS-10 4.1' (1.25 m) measuring range, non-contact transmitter, SPST programmable relays, 1" NPT thread. Delivery time from 12 weeks from 781.2 $
-
+
ULS-ACC-USB USB adapter for calibration, PVC. *USB adapter necessary for calibration. One adapter can program multiple units. Delivery time from 12 weeks from 114.55 $
-
+
ULS-ACC-121 2" x 1" NPT reducer bushing fitting (Sch. 40), PVC Delivery time from 12 weeks from 40.35 $
-
+
ULS-ACC-131 3" x 2" NPT reducer bushing fitting (Sch. 40), PVC Delivery time from 12 weeks from 84.35 $
-
+
ULS-ACC-132 3" x 2" NPT reducer bushing fitting (Sch. 80), PVC Delivery time from 12 weeks from 148 $
-
+
ULS-ACC-221 2" socket x 1" NPT reducer bushing fitting (Sch. 40), PVC Delivery time from 12 weeks from 22.25 $
-
+
ULS-ACC-222 2" Socket x 1" NPT reducer bushing fitting (Sch. 80), PVC Delivery time from 12 weeks from 80.75 $
-
+
ULS-ACC-231 3" Socket x 2" NPT reducer bushing fitting (Sch. 40), PVC Delivery time from 12 weeks from 33.9 $
-
+
ULS-ACC-241 4" Socket x 2” NPT reducer bushing fitting (Sch. 40), PVC Delivery time from 12 weeks from 60.55 $
-
+
ULS-ACC-510 1" NPT polypropylene side mount bracket Delivery time from 12 weeks from 111.45 $
-
+
ULS-ACC-520 2" NPT polypropylene side mount bracket Delivery time from 12 weeks from 96.7 $
-
+
Expand Table

User Guide and Instruction manual for DWYER ULSS

You can request the necessary certificates, documentation, instructions and user guide for DWYER ULSS using the special form.

You can buy DWYER ULSS in UAE at a price starting from 781.2 $ in «Texair FZCO» by leaving a request on the website, by phone +441225535040 or by email . DWYER ULSS price are subject to change depending on exchange rates. We deliver instruments by transport companies in United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain and other Middle Eastern countries.
