Manual hydrocarbon and water dew-point tester for natural gas
Made in United Kingdom. brand Michell, model CDP301
International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.
price По запросу
Available
Only the best I&C brands
Our company is a UAE supplier of control and measuring instruments from well-known world brands
Discounts for organisations
We sell high-tech equipment at best prices. We provide really advantageous conditions for partners
Fast delivery across the Middle East
Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries
Professional advice on device selection
Our specialists are ready to advise you on any technical question. We can find an analogue of any device
CDP301 portable HCDP tester uses the chilled mirror principle for both hydrocarbon and water dew point measurements and is designed to follow the requirements as described in ASTM D1142. Based on the visual manual method of observing the formation of condensate, the CDP301 uses a high-definition visual image to assist users and allows image capture and reliable logging of measurements for later review.
Applications
| Hydrocarbon & Water Dew-Point Measurement | |
| Measuring Technique | Chilled mirror |
| Sensor Cooling | Automated cooling ramp rate selectable according to ASTM D1142 or ISO6327 measurement practice |
| Maximum Range | Depression range up to Δ T >65 °C (149 °F) |
| Accuracy | ±0.5 °C (±0.9 °F) |
| Resolution | 0.1 °C, 0.1 °F |
| Sample Flow | 0.25…0.5 Nl/min |
| Pressure Measurements HCDP & WDP | |
| Units | MPa, barg, psig |
| Resolution | 0.1 MPa, 0.1 barg, 1 psig |
| Accuracy | ±0.25% FS |
| Dew-Point Tester | |
| Operating Pressure | Up to 100 barg (1450 psig) |
| Sample Supply Pressure | 20…100 barg (290…1450 psig) |
| Enclosure | Cast LM25 Alloy IP64 (NEMA4 equivalent) |
| Gas Connections | ¼” NPT |
| Operating Environment | -30 °C…+50 °C (-22 °F…+122 °F) max 95% rh |
| Power Supply | Rechargeable Li-ion battery, up to 8 hours’ life from full charge |
| Weight | 8 kg (17.6 lb) |
| Display & User Interface | High-definition 5.7” full-color display, operated by 5 push buttons |
| Logging/Image Capture | 2GB onboard data storage |
| Hazardous Area Certification | ATEX/UKCA: II 2 G Ex db ia IIB+H2 T3 Gb (Tamb -30 °C…+50 °C) IECEx: Ex db ia IIB+H2 T3 Gb (Tamb -30 °C…+50 °C) cQPSus: Class I, Division 1, Groups BCD T3 (Tamb -25 °C…+50 °C) Class I, Zone 1 AEx db ia IIB+H2 T3 Gb (Tamb -30 °C…+50 °C) Ex db ia IIB+H2 T3 Gb (Tamb -30 °C…+50 °C) |
| Data Transfer | USB Standard B connector for log/image transfer (safe area only) |
| Mounting | 5/8 inch 11 UNC thread suitable for tripod mount. Optional bench top mount. |
You can request the necessary certificates, documentation, instructions and user guide for Michell CDP301 using the special form.
You can buy Michell CDP301 in UAE at a price starting from По запросу $ in «Texair FZCO» by leaving a request on the website, by phone +441225535040 or by email rop@texairmeasure.ae. Michell CDP301 price are subject to change depending on exchange rates. We deliver instruments by transport companies in United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain and other Middle Eastern countries.
