QTLD/R reduced bore electromagnetic flow meter is ideal for these applications with zero upstream or downstream piping as they can better handle distorted velocity flow profiles arising from the pipe networks, allowing total flexibility in installation for demanding applications compared with full bore magnetic flow meter. It can increase velocity and flow if it’s low flow.
Made in China. brand Q&T Instrument, model QTLD/R
International delivery to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain, Oman and other Middle Eastern countries.
Our warehouses are located in UAE. Delivery to other countries (Europe, North and South America, Asia, Africa) is discussed individually.
price По запросу
Available
Only the best I&C brands
Our company is a UAE supplier of control and measuring instruments from well-known world brands
Discounts for organisations
We sell high-tech equipment at best prices. We provide really advantageous conditions for partners
Fast delivery across the Middle East
Supply to United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Bahrain, Oman and other countries
Professional advice on device selection
Our specialists are ready to advise you on any technical question. We can find an analogue of any device
Application
Features
| Size | DN50-DN300 (2″-12″) |
| Sensor | Reduced bore, U0+D0, don’t need any straight pipe in the upstream and downstream |
| Accuracy | ±0.5% of reading at flow velocity ≥0.5m/s ±0.2% optional at flow velocity ≥0.5m/s |
| Velocity | 0.1~15 m/s |
| Repeatability | ≤0.17% |
| Structure | Compact / remote, cable length 10m standard, 100m max |
| Conductivity | > 5 μS/cm, demineralized water > 20 μS/cm |
| Protection Grade | Transmitter: IP65 standard, IP67 optional |
| Sensor: IP65 standard, IP68 (submersible, only available for remote type) | |
| Electrode | SS316L, Hastelloy C, Hastelloy B, Titanium,Tantalum, Platinum-iridium |
| Power Supply | 85~250 VAC (50/60 Hz), 8~36 VDC, 3.6V lithium battery |
| Power Consumption | <20W |
| Signal Output | Analog: 4~20mA ( load resistor 0~750Ω) |
| Frequency: Forward & reverse flow output with a frequency range of 1~5000Hz | |
| Alarm: Two isolated open collector transistor (OCT) outputs for alarm signals | |
| Communication | RS485 MODBUS standard, HART, GPRS, PROFIBUS optional |
| Display | LCD Display,128X128mm, three lines, 4 buttons |
| Ambient Temperature | -20℃~60℃ |
| Fluid Temperature | Compact: -20℃~80℃ Remote: -20℃~120℃ |
| Liner Material | Neoprene, hard rubber |
| Process connection | Flange |
| Sensor Material | Measuring tube: SS304 |
| Flange & housing: carbon steel (standard), SS304 / SS316 optional | |
| Transmitter Material | Aluminium alloy with epoxy painting |
| Display | Instantaneous flow, total flow, flow velocity |
| Function | High and low alarm, empty pipe alarm, exciting alarm, self-diagnosis |
| Totalizer | Three built-in totalizers: forward flow, reverse flow and net flow |
| Display Unit | L/s, L/m, L/h, m3/s, m3/m, m3/h, UKG, USG, gal/s, gal/m, gal/h, kg/s, kg/m, kg/h, t/s, t/m, t/h |
| Language | English, Chinese, Italian, Portuguese, French, Spanish, Korean |
You can request the necessary certificates, documentation, instructions and user guide for Q&T Instrument QTLD/R using the special form.
You can buy Q&T Instrument QTLD/R in UAE at a price starting from По запросу $ in «Texair FZCO» by leaving a request on the website, by phone +441225535040 or by email rop@texairmeasure.ae. Q&T Instrument QTLD/R price are subject to change depending on exchange rates. We deliver instruments by transport companies in United Arab Emirates, Kuwait, Qatar, Saudi Arabia, Saudi Arabia, Bahrain and other Middle Eastern countries.
